| Product classification |
| Regional Availability |
Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Portfolio |
SYSTIMAX® |
| Product Type |
Twisted pair patch cord |
| Product Brand |
GigaSPEED XL® |
| Product Series |
CPC |
| Ordering Note |
Cords < 1 m are valid elements for use in a channel or as an equipment interconnect but due to their limited length are not guaranteed to meet component compliance requirements that were developed to assess the quality of longer cords | Cords > 1 m are authorized for use in channels and are an effective standalone method used to connect active devices |
| General Specifications |
| ANSI/TIA Category |
6 |
| Cable Type |
U/UTP (unshielded) |
| Conductor Type |
Solid |
| Information Outlet Color |
Black |
| Interface, Connector A |
Information outlet |
| Interface Feature, connector A |
Standard |
| Interface, Connector B |
Information outlet |
| Interface Feature, connector B |
Standard |
| Jacket Color |
Blue | White |
| Pairs, quantity |
4 |
| Transmission Standards |
ANSI/TIA-568.2-D | ISO/IEC 11801 Class E |
| Wiring |
T568B |
